MX3117概述：
    MX3117是VDS=-30V, ID=-7A,RDS(ON)(Typ.)=23mΩ@VGS=-4.5V,RDS(ON)(Typ.)=17mΩ@VGS=-10V, 的P沟道MOSFET,MX3117丝印3117C，MX3117提供SOT23-3L封装。
    The MX3117 uses advanced trench technology to provide excellent R DS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.

MX3117特性：
VDS =-30V, I D =-7A
RDS(ON) (Typ.)=23mΩ @ V GS =-4.5V
RDS(ON) (Typ.)=17mΩ @ V GS =-10V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
MX3317提供SOT23-3L封装

MX3117应用：
PWM applications
Load switch
Power management

MX3117 ORDERING INFORMATION：

MX3117典型应用原理图及封装图：
