S-P-MOS

MX3415L SOT23

    MX3415L是VDS=-20V, ID=-4A,RDS(ON) (Typ.)=42mΩ@VGS=-2.5V,RDS(ON)(Typ.)=32mΩ@VGS =-4.5V的P沟道MOSFET.
    MX3415L提供SOT23封装。
    The MX3415L uses advanced trench technology to provide excellent R DS(ON) , low gate charge and operation with gate voltages as low as -2.5V.
    This device is suitable for use as a load switch applications.
    MX3415L概述:
        MX3415L是VDS=-20V, ID=-4A,RDS(ON) (Typ.)=42mΩ@VGS=-2.5V,RDS(ON)(Typ.)=32mΩ@VGS =-4.5V的P沟道MOSFET.
        MX3415L提供SOT23封装。
        The MX3415L uses advanced trench technology to provide excellent R DS(ON) , low gate charge and operation with gate voltages as low as -2.5V.
        This device is suitable for use as a load switch applications.

    MX3415L特性:
    V DS =-20V, I D =-4A
    R DS(ON) (Typ.)=42mΩ @ V GS =-2.5V
    R DS(ON) (Typ.)=32mΩ @ V GS =-4.5V
    High Power and current handing capability
    Lead free product is acquired
    ESD Rating 4000V HBM

    MX3415L应用:
    PWM applications
    Load switch
    Power management

    MX3415L订购信息:

    Part Number

    StorageTemperature

    Package

    Devices Per Reel

    MX3415L

    -55°C to 150°C

    SOT-23

    3000



    MX3415L典型应用及引脚:
