单N-MOS

PE8810A TSSOP8

    PE8810A是VDS=18V,ID=8A,RDS(ON)<16mΩ @VGS=4.5V,RDS(ON)<18mΩ @VGS=3.8V,RDS(ON)<20mΩ @VGS=3.1V,RDS(ON)<22mΩ @VGS=2.5V的N沟道MOSFET.
    PE8810A的丝印是PE8810A,PE8810A提供TSSOP-8封装。
    The PE8810A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.
    PE8810A概述:
        PE8810A是VDS=18V,ID=8A,RDS(ON)<16mΩ @VGS=4.5V,RDS(ON)<18mΩ @VGS=3.8V,RDS(ON)<20mΩ @VGS=3.1V,RDS(ON)<22mΩ @VGS=2.5V的N沟道MOSFET.
        PE8810A的丝印是PE8810A,PE8810A提供TSSOP-8封装。
        The PE8810A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.

    PE8810A特性:
    VDS = 18V, ID = 8A
    RDS(ON) < 16mΩ  @ VGS=4.5V
    RDS(ON) < 18mΩ  @VGS=3.8V
    RDS(ON) < 20mΩ  @VGS=3.1V
    RDS(ON) < 22mΩ  @VGS=2.5V
    ESD Rating: 4000V HBM
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE8810A应用:
    PWM applications
    Load switch

    PE8810A典型应用及引脚:
