单N-MOS

PE8810B TSSOP-8

    PE8810B是VDS=18V,ID=7A,RDS(ON)<18mΩ @VGS=4.5V,RDS(ON)<19mΩ @VGS=3.8V,RDS(ON)<22mΩ @VGS=3.1V,RDS(ON)<25mΩ @VGS=2.5V的N沟道MOSFET。
    PE8810B的丝印是PE8810B,PE8810B提供TSSOP-8封装。
    The PE8810B uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.
    PE8810B概述:
        PE8810B是VDS=18V,ID=7A,RDS(ON)<18mΩ @VGS=4.5V,RDS(ON)<19mΩ @VGS=3.8V,RDS(ON)<22mΩ @VGS=3.1V,RDS(ON)<25mΩ @VGS=2.5V的N沟道MOSFET。
        PE8810B的丝印是PE8810B,PE8810B提供TSSOP-8封装。
        The PE8810B uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.

    PE8810B特性:
    VDS = 18V, ID = 7A
    RDS(ON) < 18mΩ  @ VGS=4.5V
    RDS(ON) < 19mΩ  @VGS=3.8V
    RDS(ON) < 22mΩ  @VGS=3.1V
    RDS(ON) < 25mΩ  @VGS=2.5V
    ESD Rating: 4000V HBM
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE8810B应用:
    PWM applications
    Load switch

    PE8810B典型应用及引脚:
