升降压芯片

ME2110

    ME2110 Series is a PFM Step-up DC/DC converter IC with low supply current by CMOS process.

    High frequency noise that occurs during switching is reduced by using advanced circuit designed, output voltage is programmable in 0.1V steps between 1.8~6.0V.A low ripple, high efficiency step-up DC/DC converter can be constructed of ME2110Xxx with only three external components. Also available is a CE (chip enable) function that reduce power dissipation during shut-down mode.

    ME2110Xxx is suitable for use with battery-powered instruments with low noise and low supply current.
    ME2110 General Description:
        ME2110 Series is a PFM Step-up DC/DC converter IC with low supply current by CMOS process. High frequency noise that occurs during switching is reduced by using advanced circuit designed, output voltage is programmable in 0.1V steps between 1.8~6.0V.A low ripple, high efficiency step-up DC/DC converter can be constructed of ME2110Xxx with only three external components. Also available is a CE (chip enable) function that reduce power dissipation during shut-down mode.
        ME2110Xxx is suitable for use with battery-powered instruments with low noise and low supply current.

    ME2110 Features:
    Low ripple and low noise
    Operating voltage range:0.9V~6.0V
    Output voltage range:1.8V~6.0V(step 0.1V)
    Output voltage accuracy:±2%
    Output Current:If VIN=1.2V and VOUT=1.9V,then IOUT=100mA
    Low start voltage:≤0.9V(at IOUT =1mA)
    Maximum oscillator frequency : 360KHz (TYP. ME2110C25)
    High Efficiency:85% (TYP.)
    Package: SOT89-3,SOT23-5,SOT23-3

    ME2110 Typical Application:
    Power source for battery-powered equipment
    Power source for wireless mouse, wireless keyboard, toys, cameras, camcorders, VCRs, PDAs, and hand-held communication equipment
    Power source for appliances which require higher cell voltage than that of batteries used in the appliances

    ME2110 Selection Guide:


    ME2110 Pin Configuration:


    ME2110 Block Diagram:


    ME2110 Typical Applications:
