PE2305AL概述：
    PE2305AL是VDS=-18V,ID=-4.5A，RDS(ON)<45mΩ，@VGS=-4.5V，RDS(ON)<60mΩ，@VGS=-2.5V的P-Channel  MOSFET.PE2305AL提供SOT-23封装.
    The PE2305AL uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE2305AL特性：
VDS = -18V, ID = -4.5A
RDS(ON) < 45mΩ@VGS=-4.5V
RDS(ON) < 60mΩ @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package

PE2305AL应用：
PWM applications
Load switch
Power management

PE2305AL典型应用及引脚：
