PE7304H概述：
PE7304H是VDS=-30V,ID=-4A，RDS(ON)<52mΩ，@VGS=-10V，RDS(ON)<85mΩ，@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.PE7304H的丝印是7304H.PE7304H提供SOT-23-3L封装.
The PE7304H uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE7304H特性：
VDS = -30V, ID = -4A
RDS(ON) < 52mΩ @ VGS=-10V
RDS(ON) < 85mΩ @VGS=-4.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE7304H应用：
PWM applications
Load switch
Power management
PE7304H典型应用及引脚：
