产品中心

< >

PE3407A是VDS=-30V,ID=-4.3A，RDS(ON)<52mΩ，@VGS=-10V，RDS(ON)<90mΩ，@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.
PE3407A的丝印是3407.PE3407A提供SOT-23封装.

The PE3407A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE3407A概述：

PE3407A是VDS=-30V,ID=-4.3A，RDS(ON)<52mΩ，@VGS=-10V，RDS(ON)<90mΩ，@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.
PE3407A的丝印是3407.PE3407A提供SOT-23封装.

The PE3407A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE3407A特性：

VDS = -30V, ID = -4.3A

RDS(ON) < 52mΩ @ VGS=-10V

RDS(ON) < 90mΩ@VGS=-4.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PE3407A应用：

PWM applications

Load switch

Power management

PE3407A典型应用及引脚：
