产品中心

< >

PE8318S是VDS=30V，ID=18A，RDS(ON)<7.2mΩ@VGS=10V，RDS(ON)<11mΩ@VGS=4.5V的N沟道MOSFET。
PE8318S的丝印是PE8318S，PE8318S提供SOP-8封装。

The PE8318S uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE8318S概述：

PE8318S是VDS=30V，ID=18A，RDS(ON)<7.2mΩ@VGS=10V，RDS(ON)<11mΩ@VGS=4.5V的N沟道MOSFET。
PE8318S的丝印是PE8318S，PE8318S提供SOP-8封装。

The PE8318S uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE8318S特性：

VDS = 30V, ID = 18A

RDS(ON) < 7.2mΩ @ VGS=10V

RDS(ON) < 11mΩ @VGS=4.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PE8318S应用：

PWM applications

Load switch

Power management

PE8318S典型应用及引脚：
