The AO3402 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V.

This device is suitable for use as a Battery protection or in other Switching application.

AO3402 Description:

The AO3402 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V.

This device is suitable for use as a Battery protection or in other Switching application.

AO3402 General Features:

VDS = 30V,ID =3A

RDS(ON) < 85mΩ @ VGS=2.5V

RDS(ON) < 70mΩ @ VGS=4.5V

High power and current handing capability

Lead free product is acquired

Surface mount package

AO3402 Application

Battery protection

Load switch

Power management

AO3402 Package Marking and Ordering Information:

Device Marking	Device	Device Package	Reel Size	Tape width	Quantity
3402	AO3402	SOT-23	Ø180mm	8 mm	3000 units

AO3402 Marking and pin assignment /Schematic diagram/SOT-23 top view
