The UP6006A series product is a high integration solution for lithium-ion/polymer battery protection.
UP6006A contains advanced power MOSFET, high-accuracy voltage detection circuits and delay circuits.
UP6006A is put into a small package and only one external component makes it an ideal solution in limited space of battery pack.
UP6006A has all the protection functions required in the battery application including overcharging, over-discharging, overcurrent and load short circuiting protection etc.
The accurate safe and full utilization charging. The low standby current drains little current from the cell while in storage.The device is only targeted for digital cellular phones, but also for any other Li-ion and Li-Poly battery-powered information appliance requiring long-term battery life.
UP6006A已停产建议用MX3510。
UP6006A已停产建议用MX3510。
UP6006A特性：
Protection of Battery Cell Reverse Connection
Integrate MOSFET
Integrate MOSFET
Over-temperature Protection
Two-step Overcurrent Detection:
Over-discharge Current
Load Short Circuiting
Charger Detection Function
0V Battery Charging Function
High-accuracy Voltage Detection
Low Current Consumption
Operation Mode: 4uA typ
Power-down Mode: 2.0uA typ
UP6006A应用：
One-Cell Lithium-ion Battery Pack
Lithium-Polymer Battery Pack
UP6006A典型应用图：
UP6006A封装示意图：
UP6006A封装示意图：
