MX3407概述：
    MX3407是VDS=-30V，ID=-4.3A，RDS(ON)(Typ.)＜100mΩ，@VGS=-4.5V，RDS(ON)(Typ.)＜50mΩ，@VGS=-10V的P沟道MOSFET.
    MX3407的丝印是J.Y3K.MX3407提供SOT23-3封装.
    TheMX3407 usesadvanced trench technology to provide excellent RDS(ON), This device is suitable for use as a load switch or in PWM applications.

MX3407特性：
VDS =-30V，ID =-4.3A
RDS(ON)(Typ.)＜100mΩ @VGS=-4.5V
RDS(ON)(Typ.)＜50mΩ @VGS=-10V
High power and current handing capability
Lead free product is acquired
Surface mount package

MX3407应用：
PWM applications
Load switch
Power management

MX3407典型应用及引脚：
