PE2023概述：
    PE2023是VDS=-20V,ID=-3.2A,RDS(ON)<95mΩ,@VGS=-4.5V,RDS(ON)<120mΩ,@VGS=-2.5V的P-Channel MOSFET.
    PE2023提供SOT-23-6L封装.
    The PE2023 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE2023特性：
VDS = -20V, ID = -3.2A
RDS(ON) < 95mΩ @VGS=-4.5V
RDS(ON) < 120mΩ @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package

PE2023应用：
PWM applications
Load switch
Power management

PE2023典型应用及引脚图：
