PE2209A概述：
    PE2209A是VDS=-20V,ID=-1.2A，RDS(ON)<195mΩ，@VGS=-4.5V，RDS(ON)<350mΩ，@VGS=-2.5V的P-Channel MOSFET.
    PE2209A提供SOT-23封装.
    The PE2209A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE2209A特性：
VDS = -20V, ID = -1.2A
RDS(ON) < 195mΩ @VGS=-4.5V
RDS(ON) < 350mΩ @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package

PE2209A应用：
PWM applications
Load switch
Power management

PE2209A典型应用及引脚：
