PE7304A概述：
PE7304A是VDS=-30V,ID=-4A，RDS(ON)<55mΩ，@VGS=-10V，RDS(ON)<65mΩ，@VGS=-4.5V，RDS(ON)<95mΩ，@VGS=-2.5V的P-Channel Enhancement Mode Power MOSFET.PE7304A的丝印是7304A.PE7304A提供SOT-23封装.
The PE7304A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide
PE7304A特性：
VDS = -30V, ID = -4A
RDS(ON) < 55mΩ @ VGS=-10V
RDS(ON) < 65mΩ @VGS=-4.5V
RDS(ON) < 95mΩ @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE7304A应用：
PWM applications
Load switch
Power management
PE7304A典型应用及引脚：
