PE8390G概述：
PE8390G是VDS=30V，ID=90A，RDS(ON)<2.4mΩ@VGS=10V，RDS(ON)<3mΩ@VGS=4.5V的N沟道MOSFET。
PE8390G的丝印是PE8390G。PE8390G提供DFN5x6-8L封装。
PE8390G的丝印是PE8390G。PE8390G提供DFN5x6-8L封装。
The PE8390G uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE8390G特性：
VDS = 30V, ID = 90A
RDS(ON) < 2.4mΩ @ VGS=10V
RDS(ON) < 3mΩ @VGS=4.5V
High Power and current handingcapability
Lead free product is acquired
Surface Mount Package
PE8390G应用：
PWM applications
Load switch
Power management
DC/DC Converter
PE8390G典型应用及引脚：
