PE8810C概述：
PE8810C是VDS=18V，ID=8.5A，RDS(ON)<13.5mΩ @VGS=4.5V，RDS(ON)<15mΩ @VGS=3.8V，RDS(ON)<16.5mΩ @VGS=3.1V，RDS(ON)<18mΩ @VGS=2.5V的N沟道MOSFET。PE8810C的丝印是PE8810C，PE8810C提供TSSOP-8封装。
The PE8810C uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.
PE8810C特性：
VDS = 18V, ID = 8.5A
RDS(ON) < 13.5mΩ @ VGS=4.5V
RDS(ON) < 15mΩ @VGS=3.8V
RDS(ON) < 16.5mΩ @VGS=3.1V
RDS(ON) < 18mΩ @VGS=2.5V
ESD Rating: 4000V HBM
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE8810C应用：
PWM applications
Load switch
PE8810C典型应用及引脚：
