MX2810概述：
    MX2810是VDS=20V，ID=8A，@VGS=4.5V，RDS(ON)(Typ.)=14mΩ，@VGS=3.8V，RDS(ON)(Typ.)=15mΩ,@VGS=2.5V，RDS(ON)(Typ.)=18mΩ，ESD Rating 2000V HBM的N沟道MOSFET.MX2810提供TSSOP-8封装.
    The MX2810 uses advanced trench technology to provideexcellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as aload switch or in PWM applications. It is ESD protested..

MX2810特性：
VDS =20V，ID =8A
@VGS=4.5V RDS(ON)(Typ.)=14mΩ
@VGS=3.8V RDS(ON)(Typ.)=15mΩ
@VGS=2.5V RDS(ON)(Typ.)=18mΩ
ESD Rating:2000V HBM
High power and current handing capability
Lead free product is acquired
Surface mount package

MX2810应用:
PWM applications
Load switch

MX2810典型应用及引脚图：
