MX8203概述：
    MX8203是VDS=20V,ID=6A，RDS(ON)(Typ.)16mΩ,@VGS=4.5V，RDS(ON)(Typ.)21mΩ，@VGS=2.5V的N沟道MOSFET.
    MX8203提供SOT23-6封装.
    The MX8203 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V.
    This device is suitable for use as a Battery protection or in other Switching applications.

MX8203特性：
VDS = 20V,ID =6A
RDS(ON) (Typ.) 16mΩ @ VGS=4.5V
RDS(ON) (Typ.) 21mΩ @ VGS=2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package

MX8203应用:
Battery protection
Load switch
Power management

MX8203典型应用及引脚图：
