PE3024KC概述：
PE3024KC是N-Channel:VDS=30V,ID=18A,RDS(ON)<14mΩ@VGS=10V,RDS(ON)<20mΩ@VGS=4.5V;P-Channel:VDS=-30V,ID=-14A,RDS(ON)<29mΩ@VGS=-10V,RDS(ON)<43mΩ@VGS=-4.5V的N+P双沟道MOSFET. PE3024K提供TO-252-4L封装.
The PE3024KC uses advanced trench technology to provide excellent RDS(ON)and low gate charge.It can be used in a wide variety of applications.
PE3024KC特性：
PE3024KC特性：
N-Channel
VDS=30V,ID=18A
RDS(ON)<14mΩ@VGS=10V
RDS(ON)<20mΩ@VGS=4.5V
P-Channel
VDS=-30V,ID=-14A
RDS(ON)<29mΩ@VGS=-10V
RDS(ON)<43mΩ@VGS=-4.5V
HighPowerandcurrenthandingcapability
Leadfreeproductisacquired
SurfaceMountPackage
PE3024KC应用：
PE3024KC应用：
DCmotor
PWMapplications
PE3024KC典型应用及引脚图：
PE3024KC典型应用及引脚图：
