PE4606概述：
PE4606是N-Channel：VDS=30V,ID=6.5A，RDS(ON)<30mΩ，@VGS=10V，RDS(ON)<42mΩ，@VGS=4.5V.P-Channel:VDS=-30V,ID=-6A,RDS(ON)<33mΩ,@VGS=-10V,RDS(ON)<44mΩ,@VGS=-4.5V的N and P Channel Enhancement Mode Power MOSFET.
PE4606的丝印是4606.PE4606提供SOP-8封装.
PE4606的丝印是4606.PE4606提供SOP-8封装.
The PE4606 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE4606特性：
PE4606特性：
N-Channel
VDS = 30V, ID = 6.5A
RDS(ON) < 30mΩ @ VGS=10V
RDS(ON) < 42mΩ @VGS=4.5V
P-Channel
VDS = -30V, ID = -6A
RDS(ON) < 33mΩ @ VGS=-10V
RDS(ON) < 44mΩ@VGS=-4.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE4606应用：
PE4606应用：
PWM applications
DC motor
PE4606典型应用及引脚：
