IP2363 is a lithium battery charge management chip that integrates PD3.0 and DP&DM input fast charge protocol and synchronous lift converter, with charging power up to 30W;

    The IP2363 supports 2/3/4/5 series cells, and the number of series cells can be selected through the external resistance setting.

    IP2363 Built-in IC temperature, battery NTC temperature and input voltage control detection loop, can intelligently adjust the charging current according to the identified charger power.

    The IP2363 enters low power mode after disconnecting the charger, and the standby current is reduced to 5μA. After entering the low power mode, plug in the charger to automatically wake up the charge.

    The IP2363 has a built-in 14-bit ADC that can accurately measure input voltage and current, battery voltage and current, and more. Information such as IP2363 charging voltage and charging current can be obtained through I2C.

    The IP2363 supports two charging indicators to display the charging status.
