MXDW01概述：
MXDW01是一款锂电保护IC， MXDW01过充检测电压:4.3±0.05V 过充释放电压:4.1±0.05V。
MXDW01采用SOT23-6 封装形式塑封。MXDW01适用于电池供电设备，电池保护板，通信产品。
MXDW01采用SOT23-6 封装形式塑封。MXDW01适用于电池供电设备，电池保护板，通信产品。
The IC is designed to protect lithium-ion battery from damage or degrading the lifetime due to overcharge, over discharge, and overcurrent for one-cell lithium-ion battery powered systems.
The ultra-small package and less required external components make it ideal to integrate the DW01 into the limited space of battery pack. The very low standby current drains little current from the cell while in storage.
The ultra-small package and less required external components make it ideal to integrate the DW01 into the limited space of battery pack. The very low standby current drains little current from the cell while in storage.
MXDW01特性：
1).0V charging function
2).High-precision overcharge protection detection voltage (±50mV)
3).Low quiescent current (VCC=3.9V ：6uA)
4).Low sleep current(VCC=2.0V ：0.6uA)
5).Two-stage overcurrent protection detection voltage
6).Delay time built-in.
7).MXDW01采用SOT23-6 封装形式塑封
MXDW01典型应用电路图：
MXDW01管脚图和管脚定义
