MX4953概述：
    MX4953是-30V,-5.3A的双P沟道增强型功率MOSFET.
    MX4953提供SOP-8封装.

    The MX4953 uses advanced trench technology to provide excellent RDS(ON),low gate charge and operation with gate voltages as low as -4.5V. This device is suitable for use as a load switch or in PWM applications.

VDS=-30V,ID=-5.3A

RDS(ON)(Typ.)44mΩ@VGS=-10V

RDS(ON)(Typ.)68mΩ@VGS=-4.5V

High Power and current handing capability

Lead free product is acquired

Surface mount package

MX4953提供SOP-8封装

MX4953应用:

PWM applications

Load switch

Power management
