PE30P17S概述：
PE30P17S是VDS=-30V,ID=-17A，RDS(ON)<6.5mΩ，@VGS=-10V，RDS(ON)<10mΩ，@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.PE30P17S的丝印是PE30P17S.PE30P17S提供SOP-8封装.
The PE30P17S uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE30P17S特性：
VDS = -30V, ID = -17A
RDS(ON) < 6.5mΩ @ VGS=-10V
RDS(ON) < 10mΩ@VGS=-4.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE30P17S应用：
PWM applications
Load switch
Power management
Battery Protection
PE30P17S典型应用及引脚图：
