PE8205L概述：
PE8205L是VDS=20V,ID=6.2A，RDS(ON)<20mΩ，@VGS=4.5V，RDS(ON)<22mΩ，@VGS=3.8V，RDS(ON)<28mΩ，@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.
PE8205L的丝印是8205..PE8205L提供SOT-23-6L封装.
PE8205L的丝印是8205..PE8205L提供SOT-23-6L封装.
The PE8205L uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE8205L特性：
VDS = 20V, ID = 6.2A
RDS(ON) < 20mΩ @ VGS=4.5V
RDS(ON) < 22mΩ @VGS=3.8V
RDS(ON) < 28mΩ @VGS=2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE8205L应用：
Battery Protection
Load switch
PE8205L典型应用及引脚：
