PED3008M PDFN3.3*3.3-8L-矽源特科技ChipSourceTek-音频功放,马达驱动,Mosfet,充电管理,锂保,触摸,LDO,升降压,AC-DC,PD协议,MCU,5G开关,移动电源,微波雷达,

产品中心

< >

PED3008M是VDS=-30V，ID=-35A，RDS(ON)<12mΩ@VGS=-10V，RDS(ON)<16mΩ@VGS=-4.5V的P沟道MOSFET。
PED3008M的丝印是3008M,PED3008M提供PDFN3.3*3.3-8L。

The PED3008M uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PED3008M概述：

PED3008M是VDS=-30V，ID=-35A，RDS(ON)<12mΩ@VGS=-10V，RDS(ON)<16mΩ@VGS=-4.5V的P沟道MOSFET。
PED3008M的丝印是3008M,PED3008M提供PDFN3.3*3.3-8L。

The PED3008M uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PED3008M特性：

VDS = -30V, ID = -35A

RDS(ON) < 12mΩ @ VGS=-10V

RDS(ON) < 16mΩ@VGS=-4.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PED3008M应用：

PWM applications

Load switch

Power management

PED3008M典型应用及引脚图：
