单P-MOS

MX2301A SOT-23

    MX2301A是P沟道的MOSFET,丝印是a.NC3A,提供SOT-23封装。
    The MX2301A uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 1.8V.
    @VGS=-2.5V RDS(ON)(Typ.)=110m?
    @VGS=-4.5V RDS(ON)(Typ.)=85m?
    High power and current handing capability
    Lead free product is acquired
    Surface mount package

    MX2301A概述
        MX2301A是P沟道的MOSFET,丝印是a.NC3A,提供SOT-23封装。
        The MX2301A uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 1.8V.
        This device is suitable for use as a load switch or in PWM applications.


    MX2301A特性

    VDS =-20V,ID =-3A
    @VGS=-2.5V RDS(ON)(Typ.)=110m?
    @VGS=-4.5V RDS(ON)(Typ.)=85m?
    High power and current handing capability
    Lead free product is acquired
    Surface mount package


    MX2301A应用

    PWM applications
    Load switch



    MX2301A典型应用及封装图
