单P-MOS

PE7408DS SOP8

    PE7408DS是VDS=-40V,ID=-8A,RDS(ON)<22mΩ,@VGS=-10V,RDS(ON)<32mΩ,@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.
    PE7408DS的丝印是PE7408DS.PE7408DS提供SOP8封装.
    The PE7408DS uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE7408DS概述:
        PE7408DS是VDS=-40V,ID=-8A,RDS(ON)<22mΩ,@VGS=-10V,RDS(ON)<32mΩ,@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.
        PE7408DS的丝印是PE7408DS.PE7408DS提供SOP8封装.
        The PE7408DS uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE7408DS特性:
    VDS = -40V, ID = -8A
    RDS(ON) < 22mΩ @ VGS=-10V
    RDS(ON) < 32mΩ @VGS=-4.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE7408DS应用:
    DC-DC converter
    Load switch
    Power management

    PE7408DS典型应用及引脚:
