单P-MOS

PE3401 SOT23-3L

    PE3401是VDS=-30V,ID=-4.2A,RDS(ON)<50mΩ,@VGS=-10V,RDS(ON)<65mΩ,@VGS=-4.5VRDS(ON)<90mΩ,@VGS=-2.5V的P-Channel MOSFET.
    PE3401提供SOT-23-3L封装.
    The PE3401 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE3401概述:
        PE3401是VDS=-30V,ID=-4.2A,RDS(ON)<50mΩ,@VGS=-10V,RDS(ON)<65mΩ,@VGS=-4.5VRDS(ON)<90mΩ,@VGS=-2.5V的P-Channel MOSFET.
        PE3401提供SOT-23-3L封装.
        The PE3401 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE3401特性:
    VDS = -30V, ID = -4.2A
    RDS(ON) < 50mΩ @ VGS=-10V
    RDS(ON) < 65mΩ @VGS=-4.5V
    RDS(ON) < 90mΩ @VGS=-2.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE3401应用:
    PWM applications
    Load switch
    Power management

    PE3401典型应用及引脚:
