S-N-MOS

PE8325DM PDFN3.3x3.3-8L

    PE8325DM是VDS=30V,ID=14A,RDS(ON)<10mΩ@VGS=10V,RDS(ON)<17mΩ@VGS=4.5V的N沟道MOSFET。
    PE8325DM的丝印是PE8325DM,PE8325DM提供PDFN3.3x3.3-8L封装。
    The PE8325DM uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE8325DM概述:
        PE8325DM是VDS=30V,ID=14A,RDS(ON)<10mΩ@VGS=10V,RDS(ON)<17mΩ@VGS=4.5V的N沟道MOSFET。
        PE8325DM的丝印是PE8325DM,PE8325DM提供PDFN3.3x3.3-8L封装。
        The PE8325DM uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE8325DM特性:
    VDS=30V,ID=14A
    RDS(ON)<10mΩ@VGS=10V
    RDS(ON)<17mΩ@VGS=4.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE8325DM应用:
    PWM applications
    Load switch
    Power management

    PE8325DM典型应用及引脚:
