S-N-MOS

9926 SOP8

    9926是VDS=20V,ID=6A,RDS(ON)<28mΩ@VGS=4.5V,RDS(ON)<38mΩ@VGS=2.5V的N沟道MOSFET。
    9926的丝印是9926A:9926提供SOP-8封装。
    The 9926 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    9926概述:
       9926是VDS=20V,ID=6A,RDS(ON)<28mΩ@VGS=4.5V,RDS(ON)<38mΩ@VGS=2.5V的N沟道MOSFET。9926的丝印是9926A:9926提供SOP-8封装。
        The 9926 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    9926特性:
    VDS = 20V, ID = 6A
    RDS(ON) < 28mΩ @ VGS=4.5V
    RDS(ON) < 38mΩ @ VGS=2.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    9926应用:
    Battery protection
    Load switch
    Power management

    9926原理图及引脚配置:
