S-N-MOS

MX2814 TSSOP8

    MX2814是VDS=20V,ID=8A,@VGS=4.5V,RDS(ON)(Typ.)=11m,@VGS=3.8V,RDS(ON)(Typ.)=12.5m,@VGS=2.5V,RDS(ON)(Typ.)=14m,ESD Rating 2000V HBM的N沟道MOSFET.MX2814提供TSSOP-8封装。
    The MX2814 uses advanced trench technology to provideexcellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as aload switch or in PWM applications. It is ESD protested..

    MX2814概述:
        MX2814是VDS=20V,ID=8A,@VGS=4.5V,RDS(ON)(Typ.)=11m,@VGS=3.8V,RDS(ON)(Typ.)=12.5m,@VGS=2.5V,RDS(ON)(Typ.)=14m,ESD Rating 2000V HBM的N沟道MOSFET.MX2814提供TSSOP-8封装。
        The MX2814 uses advanced trench technology to provideexcellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as aload switch or in PWM applications. It is ESD protested..

    MX2814特性:

    VDS =20V,ID =8A
    @VGS=4.5V RDS(ON)(Typ.)=11m
    @VGS=3.8V RDS(ON)(Typ.)=12.5m
    @VGS=2.5V RDS(ON)(Typ.)=14m
    ESD Rating:2000V HBM
    High power and current handing capability
    Lead free product is acquired
    Surface mount package

    MX2814应用:

    PWM applications
    Load switch

    MX2814典型应用及引脚:
