Switch voltage rise and fall

XYT4256

    XYT4256 is a dual series lithium battery synchronous boost charging chip with high integration and high reliability.
    XYT4256 can be configured with external resistance charging current, the charging system integrates 3 loops: input voltage, output voltage and output current, providing excellent performance for the charging system. The charging efficiency is 94% when the input voltage is 5V, the BAT voltage is 8.4V, and the charging current is 1.2A. Charging integrates various protection functions: input overvoltage, input undervoltage, output overvoltage, output short circuit, chip overtemperature, and a maximum charging time of 24 hours.
    XYT4256概述:
        XYT4256是一款兼具高集成度和高可靠性的双节串联锂电池同步升压充电芯片。
        XYT4256可用外部电阻配置充电电流,充电系统集成3个环路:输入电压,输出电压,输出电流,为充电系统提供卓越的性能,输入电压5V,BAT电压8.4V,充电电流1.2A时充电效率94%。充电集成了各种保护功能:输入过压,输入欠压,输出过压, 输出短路,芯片过温,以及最大充电时间24小时。

    XYT4256特性:
    输入电压工作范围4.6V~5.5V
    5V/2A 输入同步升压充电
    外部电阻调节充电电流
    输入自适应充电
    支持4.2V、4.35V 电池(4.35V 电池需定制)
    LED 显示充电状态,支持双色灯显示
    涓流/恒流/恒压充电
    充电24 小时超时保护
    输出过流、过压、短路保护
    输入过压、欠压保护
    输入耐压13V
    OTP 过温保护
    4KV ESD 特性
    封装形式:ESOP8

    XYT4256应用:
    双节串联锂电池充电

    XYT4256应用电路图:

    XYT4256引脚定义:
