CST1507双通道直流马达驱动器，双通道内置功率MOS全桥驱动，驱动前进、后退、停止及刹车功能，超低的待机电流和工作电流，低导通电阻（1.0Ω），宽电压工作范围，
CST1507采用SOP-16封装形式，
CST1507产品应用于，玩具马达驱动

It is recommended to use CST6508, which is more cost-effective

CST1507概述

CST1507双通道直流马达驱动器，双通道内置功率MOS全桥驱动，驱动前进、后退、停止及刹车功能，超低的待机电流和工作电流，低导通电阻（1.0Ω），宽电压工作范围， CST1507采用SOP-16封装形式，CST1507产品应用于，玩具马达驱动

CST1507特性
双通道内置功率 MOS 全桥驱动
驱动前进、后退、停止及刹车功能
超低的待机电流和工作电流
低导通电阻（1.0Ω）
宽电压工作范围
CST1507采用 SOP-16 封装形式

It is recommended to use CST6508, which is more cost-effective
CST1507产品应用

玩具马达驱动

CST1507典型应用电路图

File Name :	Format:	Download:
ChipSourceTek-2024 Product Col...	PDF
ChipSourceTek 2023 product col...	PDF
ChipSourceTek 2020 color page	PDF
CST6508 DataSheet	PDF
ChipSourceTek drive line and 1...	PDF
CST1507 DataSheet	PDF
