A representative development scheme of vibrator MCU

Time:2021-12-03 Views:2302
The company has a professional development team to help customers develop solutions free of charge

A representative (MCU scheme for female adult products) vibrator MUC development scheme:

Function: vibration motor
3.7V lithium battery (can be charged without polarity, magnetic attraction, USB, or micro, type-C)
Input power supply: dc5.0v/500ma
Standby power consumption: less than 10uA
Charging current: 500mA
1. When charging, the indicator light flashes and is on for a long time.
2. Long press the key to start the vibration motor, short press the 10 frequency switch, and long press the key to close the vibration motor.
3. Low battery prompt alarm (low battery prompt and low battery protection when the battery is lower than 10%)
4. Customized development






The above is ChipSourceTek MCU development engineer, A representative (MCU scheme for female adult products) vibrator MUC development scheme:

   ChipSourceTek focuses on the design and development of MCU application scheme, and provides 8-bit MCU, 32-bit MCUaudio, driverMOSFETcharging managementlithium protectiontouch controlDC-DCAC-DCPD protocolMCU5g emissionspecial chip, etc.
