Development of an aircraft cup MCU scheme

Time:2021-12-02 Views:2350
The company has a professional development team to help customers develop solutions free of charge

This is a representative (male adult products) MCU development scheme for aircraft cup

Function:
Vibrating motor
Telescopic motor
Sound from horn (earphone)
3.7V lithium battery
Input power supply: dc5.0v/500ma
Standby power consumption: less than 10uA
Charging current: 500mA
1. When charging, the indicator light is on, and it is on for a long time.
2. Long press the motor key to start the vibration and telescopic motor, short press the 10 frequency switch, and long press the motor key to close the vibration and telescopic motor.
3. Long press the sound key to turn on the sound, and long press the sound key to turn off the sound.
4. When the battery is lower than 10%, low power prompt and low power protection shall be provided
5: Support function customization development





The above is ChipSourceTek MCU development engineer, MCU development scheme of aircraft cup

   ChipSourceTek focuses on the design and development of MCU application scheme, and provides 8-bitMCU, 32-bit MCUaudio, driverMOSFETcharging managementlithium protectiontouch controlDC-DCAC-DCPD protocolMCU5g emissionspecial chip, etc.
