PE9435是VDS=-30V，ID=-5.1A，RDS(ON)<55mΩ @VGS=-10V，RDS(ON)<90mΩ @VGS=-4.5V的P沟道MOSFET。
PE9435的丝印是9435，PE9435提供SOP-8封装。

The PE9435 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE9435概述：

PE9435是VDS=-30V，ID=-5.1A，RDS(ON)<55mΩ @VGS=-10V，RDS(ON)<90mΩ @VGS=-4.5V的P沟道MOSFET。PE9435的丝印是9435，PE9435提供SOP-8封装。

The PE9435 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE9435特性：

VDS = -30V, ID = -5.1A

RDS(ON) < 55mΩ @ VGS=-10V

RDS(ON) < 90mΩ @VGS=-4.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PE9435应用：

PWM applications

Load switch

Power management

PE9435典型应用及引脚：
