PED2405是VDS=-30V，ID=-9A，RDS(ON)<33mΩ@VGS=-10V，RDS(ON)<47mΩ@VGS=-4.5V的P沟道MOSFET。
PED2405的丝印是2405，PED2405提供UDFN2x2-6L封装。

The PED2405 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PED2405概述：

PED2405是VDS=-30V，ID=-9A，RDS(ON)<33mΩ@VGS=-10V，RDS(ON)<47mΩ@VGS=-4.5V的P沟道MOSFET。PED2405的丝印是2405，PED2405提供UDFN2x2-6L封装。

The PED2405 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PED2405特性：

VDS = -30V, ID = -9A

RDS(ON) < 33mΩ @ VGS=-10V

RDS(ON) < 47mΩ @VGS=-4.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PED2405应用：

PWM applications

Load switch

Power management

PED2405典型应用及引脚：
