PED2407是VDS=-30V，ID=-5.7A，RDS(ON)<45mΩ@VGS=-10V，RDS(ON)<55mΩ@VGS=-4.5V，RDS(ON)<80mΩ@VGS=-2.5V的P沟道MOSFET。
PED2407的丝印是6N34,PED2407提供UDFN2x2-6L封装。

The PED2407 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PED2407概述：

PED2407是VDS=-30V，ID=-5.7A，RDS(ON)<45mΩ@VGS=-10V，RDS(ON)<55mΩ@VGS=-4.5V，RDS(ON)<80mΩ@VGS=-2.5V的P沟道MOSFET。PED2407的丝印是6N34,PED2407提供UDFN2x2-6L封装。

The PED2407 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PED2407特性：

VDS = -30V, ID = -5.7A

RDS(ON) < 45mΩ @ VGS=-10V

RDS(ON) < 55mΩ @VGS=-4.5V

RDS(ON) < 80mΩ @VGS=-2.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PED2407应用：

PWM applications

Load switch

Power management

PED2407典型应用及引脚：
