PE30D10是VDS=30V,ID=10A，RDS(ON)<13mΩ，@VGS=10V，RDS(ON)<18mΩ，@VGS=4.5V的N-Channel Enhancement Mode Power MOSFET.
PE30D10的丝印是30D10.PE30D10提供SOP-8封装.

The PE30D10 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE30D10概述：

PE30D10是VDS=30V,ID=10A，RDS(ON)<13mΩ，@VGS=10V，RDS(ON)<18mΩ，@VGS=4.5V的N-Channel Enhancement Mode Power MOSFET.PE30D10的丝印是30D10.PE30D10提供SOP-8封装.

The PE30D10 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE30D10特性：

VDS = 30V, ID = 10A

RDS(ON) < 13mΩ @ VGS=10V

RDS(ON) < 18mΩ@VGS=4.5V

High Power and current handingcapability

Lead free product is acquired

Surface Mount Package

PE30D10应用：

PWM applications

Load switch

Power management

PE30D10典型应用及引脚图：
