FM16 (16M存储器)

The FM16 is 16M-bit Serial Peripheral Interface (SPI) Flash memory, and supports the Dual SPI: Serial Clock, Chip Select, Serial Data I/O0 (SI), I/O1 (SO). The Dual Output data is transferred with speed of 108Mbits/s. The device uses a single low volt

在线咨询

产品详情 资料下载 在线询价

FM16概述

Additionally, the device supports JEDEC standard manufacturer and device ID.

In order to meet environmental requirements, Boya Microelectronics offers an 8-pin SOP 150-mil, 173-mil or 208mil, an 8-pad USON 3x3-mm, DFN3*3, and other special order packages, please contacts Boya Microelectronics for ordering information.

FM16特性
● erial Peripheral Interface (SPI)
- Standard SPI: SCLK, /CS, SI, SO, /WP
- Dual SPI: SCLK, /CS, IO0, IO1, /WP
● Read
- Normal Read (Serial): 55MHz clock rate
- Fast Read (Serial): 108MHz clock rate
- Dual Read: 108MHz clock rate SOP8 150-mil
● Program
- Serial-input Page Program up to 256bytes
● Erase
- Block erase (64/32 KB)
- Sector erase (4 KB)
- Chip erase
● Program/Erase Speed
- Page Program time: 0.7ms typical
- Sector Erase time: 100ms typical
- Block Erase time: 0.3/0.5s typical
- Chip Erase time: 15s typical SOP8 208-mil
● Flexible Architecture
- Sector of 4K-byte
- Block of 32/64K-byte
● Low Power Consumption
- 20mA maximum active current
- 5uA maximum power down current
● Software/Hardware Write Protection
- Enable/Disable protection with WPPin
- Write protect all/portion of memory via software
- Top or Bottom, Sector or Block selection
● Single Supply Voltage
- Full voltage range: 2.7~3.6V USON8 3*3 mm
● Temperature Range
- Commercial (0℃ to +70℃)
- Industrial (-40℃ to +85℃)
● Cycling Endurance/Data Retention

- Typical 100k Program-Erase cycles on any sector

- Typical 20-year data retention at +55℃

FM16封装图

FM16引脚配置

FM16逻辑图
