PED20D09M概述：
PED20D09M是VDS=-18V，ID=-9A，RDS(ON)<20mΩ@VGS=-10V，RDS(ON)<25mΩ@VGS=-4.5V，RDS(ON)<30mΩ@VGS=-2.5V的P沟道MOSFET。PED20D09M的丝印是20D09M,PED20D09M提供PDFN3.3x3.3-8L封装。
The PED20D09M uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PED20D09M特性：
VDS = -18V, ID = -9A
RDS(ON) < 20mΩ @VGS=-10V
RDS(ON) < 25mΩ @VGS=-4.5V
RDS(ON) < 30mΩ @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PED20D09M应用：
PWM applications
Load switch
Power management
PED20D09M典型应用及引脚：
