PED805概述：
PED805是VDS=-12V，ID=-8.5A，RDS(ON)<18mΩ，@VGS=-4.5V，RDS(ON)<25mΩ@VGS=-2.5V的P沟道MOSFET。PED805的丝印是D805，PED805提供UDFN2x2-6L封装。
The PED805 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PED805特性：
VDS =-12V, ID =-8.5A
RDS(ON) < 18mΩ @VGS=-4.5V
RDS(ON) < 25mΩ @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PED805应用：
PWM applications
Load switch
Power management
Battery Protection
PED805典型应用及引脚：
