PED30D12M概述：
PED30D12M是VDS=30V，ID=12A，RDS(ON)<14mΩ@VGS=10V，RDS(ON)<20mΩ@VGS=4.5V的N沟道MOSFER。PED30D12M的丝印是30D12M，PED30D12M提供PDFN3.3x3.3-8L封装。
The PED30D12M uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PED30D12M特性：
VDS = 30V, ID = 12A
RDS(ON) < 14mΩ @ VGS=10V
RDS(ON) < 20mΩ @VGS=4.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PED30D12M应用：
PWM applications
Load switch
Power management
PED30D12M典型应用及引脚：
