PED2310L概述：
PED2310L是VDS=18V，ID=8A，RDS(ON)<15mΩ@VGS=4.5V，RDS(ON)<17mΩ@VGS=3.8V，RDS(ON)<19mΩ@VGS=3.1V，RDS(ON)<22mΩ@VGS=2.5V的N沟道MOSFET.PED2310L的丝印是NG25,PED2310L提供DFN2x3-6L封装。
The PED2310L uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.
PED2310L特性：
VDS = 18V, ID = 8A
RDS(ON) < 15mΩ @ VGS=4.5V
RDS(ON) < 17mΩ @VGS=3.8V
RDS(ON) < 19mΩ @VGS=3.1V
RDS(ON) < 22mΩ @VGS=2.5V
ESD Rating: 4000V HBM
High Power and current handing capability
Lead free product is acquired
Surface Mount
PED2310L应用：
PWM applications
Load switch
Power management
PED2310L典型应用及引脚：
