TX78XX is three-terminal positive regulators. One of these regulators can deliver up to 1A of output cu r rent.
    The inte rnal limiting and therm al-shutdown features of the regulator make them essentially immune to overload.
    When used as a replacement for a zener diode-resistor Combination, an effective improvement in output impedance can be obtained, together with lower quiescent current.

Output Current of 1A

Thermal Overload Protection

Short Circuit Protection

Output transistor safe area protection

No external components

Package：TO220

Output voltage accuracy: tolerance ±5%

TX78XX Selection Table:

Part No.	Output Voltage	Package	Marking
TX7805	5.0V	TO220
TX7806	6.0V
TX7808	8.0V
TX7809	9.0V
TX7812	12V
