Development of MCU scheme for LED electronic candle lamp
Time:2021-11-24
Views:2331
The company has a professional development team to help customers develop solutions free of charge
Development of MCU scheme for LED electronic candle lamp
Development of MCU scheme for LED electronic candle lamp
LED electronic candle lamp MCU scheme can emit comfortable flashing light like a real candle. It has the effect of simulated candle and is suitable for some parties or celebrations. Low cost led candle lamp IC scheme launched by siyuante technology.
LED electronic candle lamp MCU scheme is a good candle substitute for families with children. It can not only create an atmosphere, but also be used as a decorative lamp without worrying about fire hazards. Therefore, it is also called led flameless lamp.
1、 Introduction to MCU scheme and function of LED electronic candle lamp
The electronic candle lamp is convenient and easy to use. The LED candle lamp IC has a built-in timer, which automatically turns on the lamp at the same time every day, and then makes it shine for 6 hours. Compared with incandescent bulbs, LED light sources can save up to 85% of energy, and the service life is 10 times longer than incandescent bulbs. LED color: white, red, yellow, blue, green, pink, and seven colors. Multiple colors are lit alternately. The LED candle lamp IC is preset with a built-in timer, and the lamp can remain on for 6 hours. It will then automatically close for 18 hours and then open again.
2、 Schematic diagram of LED electronic candle lamp MCU scheme
3、 MCU scheme features of LED electronic candle lamp
ChipSourceTek focuses on the design and development of MCU application scheme, and provides 8-bit MCU, 32-bit MCU, audio, driver, MOSFET, charging management, lithium protection, touch control, DC-DC, AC-DC, PD protocol, MCU, 5g emission, special chip, etc.2、 Schematic diagram of LED electronic candle lamp MCU scheme
3、 MCU scheme features of LED electronic candle lamp
The MCU scheme of LED electronic candle lamp is a static CMOS chip integrating high speed, small volume, ultra-low power consumption and anti high noise. Mainly used in: kerosene lamp, candle lamp and other lighting products.
Sleep low power consumption;
Support function customization.
The above is the MCU scheme of LED electronic candle lamp developed by ChipSourceTek MCU development engineer.
The above is the MCU scheme of LED electronic candle lamp developed by ChipSourceTek MCU development engineer.
