单P-MOS

PED505 DFN2x2-6L

    PED505是VDS=-20V,ID=-5A,RDS(ON)<45mΩ@VGS=-4.5V,RDS(ON)<60mΩ@VGS=-2.5V的P沟道MOSFET。
    PED505的丝印是D505,PED505提供DFN2x2-6L封装。
    The PED505 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PED505概述:
        PED505是VDS=-20V,ID=-5A,RDS(ON)<45mΩ@VGS=-4.5V,RDS(ON)<60mΩ@VGS=-2.5V的P沟道MOSFET。PED505的丝印是D505,PED505提供DFN2x2-6L封装。
        The PED505 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PED505特性:
    VDS = -20V, ID = -5A
    RDS(ON) < 45mΩ@VGS=-4.5V
    RDS(ON) < 60mΩ@VGS=-2.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PED505应用:
    PWM applications
    Load switch
    Power management

    PED505典型应用及引脚:
