LDO

TX6251

    The TX6251 series is a group of positive voltage output, three-pin regulators, that provide a high current even when the input/output voltage differential is small.Low power consumption and high accuracy is achieved through CMOS and laser trimming technologies.

    The TX6251 consists of a high-precision voltage reference, an error amplification circuit, and a current limited output driver.

    Transient response to load variations have improved in comparison to the existing series.

    SOT89-3 SOT89-5 TO92 SOT223 TO252 TO263 and TO220 packages are available.
    TX6251 General Description:
        The TX6251 series is a group of positive voltage output, three-pin regulators, that provide a high current even when the input/output voltage differential is small.Low power consumption and high accuracy is achieved through CMOS and laser trimming technologies.The TX6251 consists of a high-precision voltage reference, an error amplification circuit, and a current limited output driver.Transient response to load variations have improved in comparison to the existing series.
        SOT89-3 SOT89-5 TO92 SOT223 TO252 TO263 and TO220 packages are available.

    TX6251 Features:
    Low voltage drop: 0.06V@100mA l High input voltage: 10V
    Low temperature coefficient
    Low Quiescent Current: 25uA at 5.0V
    Output voltage accuracy: tolerance ±1%

    TX6251 Applications:
    Battery-powered equipment
    Hand-Hold Equipment
    GRS Receivers
    Wireless LAN

    TX6251 Order Information:
    TX6251 Typical Application:
    TX6251 Block Diagram:
    TX6251 Pin Assignment:
